2018 Jeep Grand Cherokee IV (WK2 facelift 2017) Trackhawk 6.2 V8 (710 Hp)





GENERAL
Brand:	Jeep
Model:	Grand Cherokee IV (WK2 facelift 2017)
Modification (Engine):	Trackhawk 6.2 V8 (710 Hp) AWD
Body Type:	5-doors, suv/crossover
Transmission:	8 speed automatic
Number Of Seats:	5
Segment:	m (large suv)
Introduction:	2018
End:	2021



DRIVE
Drive Wheel :	all wheel drive
Engine/motor Type:	fuel engine
Fuel Type:	gasoline
Power:	522 kw (710 hp)
Total Max. Power (kW):	522
Total Max. Power (hp):	710
Max Torque:	875 nm



FUEL ENGINE
Cylinders:	8, v engine
Valves Per Cylinder:	2
Engine Capacity:	6166 cc
Bore X Stroke:	103,9 x 90,9 mm
Compression Ratio:	9,5 :1
Max Power:	522 kw (710 hp)
Power (kW):	522
Power (hp):	710
Max. Power Rpm:	6000 rpm
Max Torque:	868 nm
Max Torque Rpm:	4300 rpm
Fuel System:	multipoint injection
Valve Actuation:	ohc
Turbo:	no
Catalyst:	regular
Fuel Tank Capacity:	94 l



PERFORMANCE
Top Speed:	289 km/h
Acceleration 0-100 Km / H:	3,7 s



CONSUMPTION (NEDC)
Urban Consumption:	25,5 l/100km
Extra-urban Consumption:	11,7 l/100km
Combined Consumption:	16,8 l/100km
Co2 Emissions:	385 g/km
Energy Label:	g



CHASSIS
Front Suspension:	independent, wishbone
Rear Suspension:	multilink
Front Suspension:	air suspension
Rear Suspension:	air suspension
Front Stabilizer:	yes
Rear Stabilizer:	yes
Front Brakes:	ventilated discs, 380 mm
Rear Brakes:	discs, 350 mm
Front Tire Size:	295/45r20
Rear Tire Size:	295/45r20
Turning Circle:	11,6 m



TRANSMISSION
1st Gear:	4,71:1
2nd Gear:	3,14:1
3rd Gear:	2,11:1
4th Gear:	1,67:1
5th Gear:	1,29:1
6th Gear:	1,00:1
7th Gear:	0,84:1
8th Gear:	0,67:1
9th Gear:
Reverse Gear:	3,30:1
Final Drive:	3,70:1
Rpm At 120 Km/h (theoretical):	2.050 rpm



WEIGHTS
Curb Weight:	2431 kg
Max. Payload:	518 kg
Max. Permissible Mass:	2949 kg
Max. Front Axle Mass:	- kg
Max. Rear Axle Mass:	- kg
Max. Braked Trailer Mass:	3500 kg
Max. Unbraked Trailer Mass:	750 kg
Max. Nose Weight:	175 kg
Max. Roof Load:	68 kg



LUGGAGE / LOAD COMPARTMENT
Cargo Capacity:	782-1554 l
Length Min./max.:
Width Min./max.:
Height:
Height Of Lift Threshold:	800 mm



EXTERIOR SIZES
Length:	4846 mm
Width:	1954 mm
Height:	1749 mm
Wheelbase:	2915 mm
Front Track Width:	1628 mm
Rear Track Width:	1634 mm
Ground Clearance:	203 mm



INTERIOR SIZES
Distance Backrest / Pedals:	900-1130 mm
Front Headroom:	920-1000 mm
Front Backrest Length:	600 mm
Front Seat Length:	500 mm
Front Entry Height:	780 mm
Front Interior Width:	1460 mm
Distance Backrest Front / Rear:	640-900 mm
Avg. Distance Backrest Front / Rear:
Rear Headroom:	950 mm
Backrest Length:	640 mm
Rear Seat Length:	490 mm
Rear Seat Height:	280 mm
Rear Interior Width:	1420 mm
